| Hole pitch/number | 05/10 |
| Packaging height (cm) | 12.5 |
| Packaging width (cm) | 32.8 |
| Packaging length (cm) | 32.8 |
| Weight (kg) | 8.6 |
| Brake disc type | internally vented |
| Min. thickness (mm) | 24 |
| Centering diameter (mm) | 65 |
| Surface | coated |
| Brake disc thickness (mm) | 26 |
| Machining | high-carbon |
| Wheel bolt bore Ø (mm) | 15.4 |
| Bolt hole circle Ø (mm) | 112 |
| Inner diameter (mm) | 145 |
| Outer diameter (mm) | 306 |
| Supplementary article/supplementary info 2 |
|
| Height (mm) | 49.7 |
| Fitting position | Front |
| Manufacturer | Productnumber |
| audi | 5WA615301 |
| audi | 5WA615301B |
| cupra | 5WA615301 |
| cupra | 5WA615301B |
| seat | 5WA615301 |
| seat | 5WA615301B |
| skoda | 5WA615301 |
| skoda | 5WA615301B |
| vw | 5WA615301 |
| vw | 5WA615301B |
| audi (faw) | 5WA615301 |
| audi (faw) | 5WA615301B |
| Usage numbers |
| A.B.S. 18997 |
| APEC DSK3574 |
| BENDIX Braking BDS2277HC |
| BLUE PRINT ADBP430169 |
| BORG & BECK BBD5660 |
| BRECO BV9695 |
| COMLINE ADC5105V |
| COMLINE AND7390 |
| DELPHI BG5166C |
| DENCKERMANN B130877 |
| DON PCD22252 |
| EBC Brakes D2289 |
| EUROBRAKE 58153147199 |
| FEBI BILSTEIN 184699 |
| FERODO DDF3121C |
| FERODO DDF3182 |
| FERODO DDF3182C |
| HELLA 8DD355134611 |
| HELLA PAGID 355134611 |
| HELLA PAGID 8DD355134611 |
| JURATEK VAG372 |
| JURID 563766JC |
| JURID 563828JC |
| MINTEX MDC3030C |
| MOTAQUIP LVBD2090 |
| NK 3147199 |
| OPTIMAL BS1074HC |
| PAGID 56348HC |
| PAGID 56348NHC |
| PAGID T3197N56348N00 |
| PAGID T3197N56348N01 |
| SWAG 33109511 |
| TEXTAR 2667701334801 |
| TEXTAR 98200334801 |
| ZIMMERMANN 600327120 |
| ZIMMERMANN 600327152 |
| ZIMMERMANN 600327153 |
| Manufacturer | Model | Version | Engine code | Construction type | Construction start | Construction end | Pk | Power kw |
 audi |
||||||||
 cupra |
||||||||
 seat |
||||||||
 skoda |
||||||||
 vw |
All our standard discs are priced individually, but due to the safety critical aspect of the braking system, Brake Discs must now be purchased in pairs where required and we will add a quantity of 2 to your basket. (Some high-performance discs are sold as a set of two). Our brake pads are sold as a front set or rear set, so purchasing one box will be enough for two discs
See the diameter on the right side of the product image .The best way to ensure you get the correct brake discs is to check the diameter of the brake discs already fitted.
Simply enter your vehicle registration or VIN on our website. Our built-in system will automatically show you the correct brake discs for your car. You can also message us if you need help.
On average, brake discs last between 30,000–70,000 miles, but this varies based on driving style and conditions. Look out for signs like vibrations, noise, or visible wear.
All our brake discs are brand new and meet or exceed OEM standards.
